Max 1,990 lbs · Boom 28.4 ft · Fits through a single door
The SPYDERCRANE URW095 is the smaller-capacity variant in the 200 Series, ideal when you need the compact single-door footprint and 28.4 ft boom of the URW295 family at a 1,990 lbs rated capacity.
Like other 200 Series models, the URW095 features variable-geometry outriggers, wireless radio remote control, and power options including gas/propane standard with diesel and battery/electric available.
| Specification | URW095 |
|---|---|
| Max Capacity | 1,990 lbs @ 12 ft |
| Boom Length | 28.4 ft |
| Approximate Tip Height | 31 ft |
| Wire Rope on Drum | ~150 ft |
| Travel Dimensions (W × H × L) | 24″ × 56″ × 108″ |
| Footprint (Max) | 12'6″ × 12'6″ |
| Footprint (Min) | 8'6″ × 7'6″ |
| Weight of Crane | ~4,300 lbs |
URW095 is a 200 Series variant for jobs requiring a smaller capacity. Specifications subject to change. Download the official spec sheet for the most current data.
| Power Configuration | URW095 |
|---|---|
| Gas / Propane | Standard |
| Diesel | Optional |
| Battery/Electric with Gas / Diesel (Dual Power) | Optional |
| 110V Battery/Electric Only | Optional |
While available in traditional gas, propane, and diesel power options, SPYDERCRANE® mini cranes also offer a zero-emission Battery/Electric option. These models run on battery power and plug into a standard 110 Volt wall outlet.
| URW095 | |
|---|---|
| Single Part Line | Optional |
| 2-Part Line | Standard |
| 4-Part Line | - |
| Jib with Searcher Hook | Standard |
| Variable Geometry Outriggers | Standard |
| Patented Overturn Protection | Standard |
| Automatic Throttle Advancement | Standard |
| On-board Self Diagnostic Computer System | Standard |
| Full Function Wireless Remote | Standard |
| Automatic Hook Stow | Standard |
Click any feature below to watch a short video and learn how it works.
| URW095 | |
|---|---|
| Attachable Work Platform | Optional |
| Non-marking Tracks | Optional |
| SPYDERWEB Glass Manipulator | Optional |
| Auxiliary Winch | Optional (400′ wire rope) |
| Propane Tank | Optional |
| Fire Extinguisher | Optional |
| Spare Parts Kit (2-Year Supply) | Optional |
| Track Mats 3' × 6' (Set of 3) | Optional |
| Outrigger Pads | Optional |
| Rigging | Optional |
| Weatherproof Cover | Optional |
Click any featured accessory below to learn more.
Photos from real SPYDERCRANE jobsites. Click any photo to view full size.
SPYDERCRANE® operator training with hands-on instruction from dedicated trainers.
